Hiab`s solution for the general supplier of buildings
Another delivery completed. We handed over the new RENAULT with hydraulic loader crane Hiab X-HiDuo 118 B-3 and hooklift Multilift XR7S.41 to the Czech company STAKO s.r.o., the general supplier of civil and residential buildings with more than 25 years of experience in this field.
Our company CONTSYSTEM s.r.o. implemented a complete delivery of the vehicle including installation and set-up of both hydraulic devices on the chassis, as well as delivery and installation of side under-run bars, rear fenders, oil tank and the pump. We also made the chassis adjustment before the assembly.
Loader crane Hiab X-HiDuo X-HiDuo 118 B-3 with three hydraulic extensions has a standard lifting capacity of 93 kNm, hydraulic reach of 10,1 m and slewing angle 406°. It is fitted with the XS-Drive remote control with 6 functions and safety and productivity boosting functions, such as VSL, ADC, OLP, CWI, SAF and signaling of non-folded support legs. The oil tank has a capacity of 100 liters and an oil flow 45 -55 l/min.
More about SAF function:
Hooklift MULTILIFT XR7S.4150 has a loading capacity of 7 tons and is used for containers from 4 to 5 meters long. It is operated with the joystick from the cabin and equipped with a number of safety functions, such as emergency external control, load-based audible signaling, NOT-AUS stop button or rear hydraulic locking.
This solution, the hydraulic crane and hooklift installed on one chassis, provides the versatile use of the truck.
On Monday, May 13, we handed over TATRA Phoenix T158 truck with loader crane Hiab X-HiDuo 298 EP-3 and hooklift Multilift XR 14S.51 to the Czech company PEDASTA dopravní stavby, s.r.o.
Our company CONTSYSTEM s.r.o. implemented a complete delivery of the vehicle including installation and set-up of both hydraulic devices on the chassis, as well as delivery and installation of accessories - rear and underun bars, rear fenders, as well as water barrel and tool box.
Hiab X-HiDuo 298 EP-3 has three hydraulic extensions, a standard lifting capacity of 237 kNm and a hydraulic reach of 10,3 m. It is fitted with the XS-Drive remote control with 4 functions and safety and productivity boosting functions, such as VSL, ADC, OLP, CWI and signaling of non-folded support legs. The oil tank has a capacity of 175 liters and a oil flow 70-90 l/min.
MULTILIFT XR14S.51 hooklift has a load capacity of 14 tons. It is operated with the joystick from the cabin and equipped with a number of safety functions, such as emergency external control, load-based audible signaling, NOT-AUS stop button or friction relief.
The "2 in 1" solution, the hydraulic crane and hooklift installed on one chassis, provides versatile use of the truck, not only in constrution and building sector.
Hiab, part of Cargotec, introduces its HiVision system for MULTILIFT hooklifts, to make hooklift operation easier, safer and quicker. HiVision creates an Augmented Reality experience by overlaying operation guidance and equipment information to real-life footage captured by rear cameras. The driver sees it on a touch-screen display inside the truck cabin that can also be used to operate the hooklift.
MULTILIFT with HiVision has three rear mounted cameras in different heights, so the driver gets full overview. The system can detect containers and with the push of a button the driver can select guidance to reverse and lift the desired container.
HiVision adds another layer of safety, as the system shows the operator whether the container is loaded and secured correctly. It also warns about any static or on-coming obstacles so the driver can stop any operation that could otherwise lead to a dangerous situation.
HiVision for MULTILIFT is specially designed to work with the recently launched MULTILIFT Ultima, the world's most advanced hooklift range. The concept will for the first time be shown at the Fair trade Transport-Logistics 2019 in Helsinki, the largest event of its kind in the Nordics region, which takes place 9 - 11 May.
Two years ago, waste collecting and handling company OZO Ostrava s.r.o. invested in two new vehicles fitted with Hiab hydraulic loader cranes with CTC software function. OZO has become the very first European company to have Hiab cranes equipped with this new software feature CTC that greatly simplifies the handling of underground containers.
In a short video, OZO Ostrava evaluates the Hiab technique, work with CTC and cooperation with Czech dealer of Hiab, company CONTSYSTEM, which provides the servicing of the handling equipment for OZO Ostrava.
CTC stands for Crane Tip Control and it is a software feature in the HiPro control system that helps you move the crane tip precisely the way you want. The control system will select the ideal path from one point to another, so that you can focus on your load instead of on your crane’s motion. The CTC is activated with a button on the hand control and the crane moves are then coordinated with one joystick. The operator no longer has to maneuver each boom and perform up to three operations to maintain the required crane trajectory in the vertical or horizontal direction. The crane will do it for him.
Lennart Andersson, Product Manager of Control Systems, explains the development behind Crane Tip Control, CTC:
Thanks to CTC, the operator can handle more complex handling tasks
With CTC, work is smoother and faster
When handling underground containers, the containers are not jammed when they are pulled out
The operator can simply activate or deactivate the CTC function by pressing a button on the hand controller. The crane immediately switches between CTC and normal mode, so the operator can always return from any situation that cannot be done with CTC.
Currently, CTC features can be equipped with cranes with state-of-the-art control systems on the market today, HiPro, the following series: X-HiPro 142E, 162E, 192E, 232E, L-HiPro 145, 165,195, 235 and K-HiPro 425. If the crane is equipped with a CTC function, it automatically has the SAF function (Semi Automatic Folding).
The delivery of hooklift for REMET, spol. s.r.o. has just been completed. CONTSYSTEM installed MULTILIFT Optima 20S.56 on Mercedes chassis.
MULTILIFT Optima 20S.56 has a load capacity of 20 tons and is operated manually from the vehicle cab. It features friction-relief, automatic sequence control, high speed and other standard safety features. The oil tank has 150 liters, the hydraulic pump is Sunfab SAP-084.
The delivery from CONTSYSTEM included a complete assembly of the hooklift on the chassis and control system set-up.
Multilift XR21S.56 for the major purchaser of scrap metal from Brno
Handover of the new vehicle with hooklift Multilift XR21S.56 and hydraulic loader crane Kesla to REMET company is completed.
Delivery from CONTSYSTEM‘ side included a complete hooklift and the hydraulic crane assembly on a three-axle chassis MAN, control system set-up, installation of the weighing system and its connection to the hydraulic system of the hooklift and the trasport of the vehicle to the customer.
MULTILIFT XR21S.56 hooklift with the capacity of 21 tons is designed for handling containers with a length of 4 500 to 6 600 mm. The weight of the hooklift is 2 500 kg and an operating pressure of 30 MPa.
This type of hooklift is designed for installation on a three to four-axle chassis.
Our partner, FISS Fiala s.r.o. opened a service hall in Brno-Pohořelice which offers servicing of hydraulic handling equipment HIAB AB. The new service hall opening extended the range of services for customers from South Moravia and Brno.
Partner company FISS Fiala, s.r.o. rented part of the hall owned by Navara, a.s. The service hall is located near the highway E 461.
Address: Znojemská 1625, 691 23 Pohořelice
Contact: FISS Fiala s.r.o. - David Fiala, 724 017 073
Fire truck with Multilift and Hiab for Czech Fire Rescue Services
We are presenting one of our newest projects for the Czech Fire Brigade of the Moravian-Silesian Region – Fire vehicle equipped with MULTILIFT XR14S.51 and loader crane HIAB X-HiDuo 188 E-6 on the chassis Tatra T815 / 7 8x8 for driving on and off-road.
Delivery of the Fire Brigade vehicle from the Contsystem’s side included: Delivery of TATRA chassis (with cooperation with TATRA TRUCKS a.s., Czech Republic) with all required adjustments of chassis, delivery and installation of Hiab loader crane and hooklift Multilift with all specified accessories, putting the vehicle into operation and carrying all functional tests, providing all necessary documents for proper registration of the vehicle, cooperation with THT Polička on delivery and installation of all warning devices, radio station and the coloring process.
Contsystem handed over the new vehicle equipped with the hydraulic loader crane HIAB X-HiPro 418 EP-5 and the rescue body OMARS on the chassis T815/7 6x6 to the Fire Brigade of Moravian-Silesian Region.
The vehicle is used for the various rescue operations. The delivery from the CONTSYSTEM side included the complete assembly including all the accessories, ensuring the coloring process, putting the vehicle into operation and carrying all the functional tests, operators‘ training, providing all the necessary documents for proper registration of the vehicle, cooperation with OMARS on delivery and installation of the rescue body, cooperation with the company THT Polička on delivery and installation of the firefighting equipment.
CONTSYSTEM has delivered two hooklifts MULLTILIFT XR 26Z.56 on Volvo chassis to one of the largest freight, rail and combined transport providers in Europe - AWT company.
MULTILIFT XR26Z.56 hooklift with a capacity of 26 tons, a tipping angle of 49 °, a maximum operating pressure of 30 MPa is designed for containers with an inner length of 3.8 - 6.6 meters. Joystick control is directly from the vehicle cabin. Easy and safe handling is provided by many other features – e.g. high loading rate, friction reduction, automatic sequential control, acoustic signaling, etc.
The delivery included: chassis modification for assembly, mounting of hooklifts on the chassis, mounting of the side barriers, reserve of the cabin, toolbox, assembly test and training of the operator.
